2008-2014 BMW X6 / X6 M (E71) CCB Big Brake Kit | Akebono 10N 10-Piston
Official Warranty: 1‑year free replacement for quality defects or coating issues under normal (non-track) use.
We Ship Worldwide
2008-2014 BMW X6 (E71) CCB Big Brake Kit — Genuine Akebono OEM Porsche 10-Piston (10N) Caliper Front + Genuine Brembo OEM Porsche 19Z 4-Piston Caliper Rear Setup
The 2008-2014 BMW X6 E71 is heavy enough to expose factory iron-brake heat capacity, pad transfer, dust, and rotor service cost when driven hard or fitted with open 21-inch wheels. This StopFlex Kit Upgrade pairs a 420mm front carbon-ceramic rotor with the Genuine Akebono OEM Porsche 10-Piston (10N) Caliper and a 380mm rear carbon-ceramic rotor with the Genuine Brembo OEM Porsche 19Z 4-Piston Caliper, giving the X6 more thermal mass at the front axle, lower rotating weight than comparable iron hardware, and cleaner wheels. Each kit is built from the confirmed E71 trim data, so brackets, rotor-hat offsets, caliper position, lines, and hardware are matched to the customer’s exact X6 rather than assumed from the chassis code.
- 420mm front carbon-ceramic rotor requires 21-inch or larger wheels on the E71 X6; spoke clearance is verified because the 10-piston Akebono front caliper is physically wide.
- Rear package uses a 380mm carbon-ceramic rotor with a Genuine Brembo OEM Porsche 19Z 4-Piston Caliper to keep rear axle contribution matched to the larger front brake package.
- E71 standard X6 and X6 M/performance variants are not treated as one fitment; StopFlex builds trim-specific brackets and rotor-hat offsets after confirming the exact vehicle configuration.
Fitment Hard Lines
| Field | Specification |
|---|---|
| Vehicle | BMW X6 (E71) |
| Model years | 2008-2014 |
| Front setup | Genuine Akebono OEM Porsche 10-Piston (10N) Caliper / 420mm |
| Rear setup | Genuine Brembo OEM Porsche 19Z 4-Piston Caliper / 380mm |
| Page type | Complete CCB kit upgrade |
| Minimum wheel size | 21" (for the 420 mm front rotor) |
Every StopFlex kit is bespoke-engineered for your exact model and trim — the brackets, rotor-hat offsets, and caliper mounting are matched to your specific car, not assumed from the platform. This matters because trims that share a chassis name can differ mechanically: a pure M or performance variant often carries different front knuckles/uprights, hub geometry, and wheel axial (ET) clearance than the standard models in the same family, so a bracket and hat offset that bolt onto one are not the same parts that fit the other. StopFlex supplies the calipers, pads, rotor hats, floating hardware, and brake lines as a matched system built to your confirmed trim. Cars with modified knuckles, modified uprights, or non-factory suspension mounting points must be reviewed before ordering and are not treated as direct-fit.
This setup uses a 420 mm front rotor, so the minimum wheel size is 21". Wheels under 21" will not clear the caliper and rotor, and spoke profile and offset affect clearance too — confirm your exact wheels before ordering.
| Wheel Size (Standard) | Disc Range |
|---|---|
| 15" | 260 mm – 285 mm |
| 16" | 285 mm – 300 mm |
| 17" | 300 mm – 330 mm |
| 18" | 330 mm – 355 mm |
| 19" | 355 mm – 380 mm |
| 20" | 380 mm – 400 mm |
| 21" | 400 mm – 420 mm |
| 22" | 420 mm – 440 mm |
Caliper Overview — Front & Rear Balance
Front Caliper (Primary Upgrade)
The front axle uses the Genuine Akebono OEM Porsche 10-Piston (10N) Caliper, a 10-piston fixed caliper selected to spread clamping force across a long pad area and support a firmer, more stable pedal under repeated high-energy stops. Its OEM Porsche provenance matters because this is an OEM-derived performance caliper, not an unbranded casting adapted only for appearance. StopFlex positions it over the 420mm carbon-ceramic rotor with brackets, hat offset, and line routing engineered for the confirmed BMW X6 E71 trim.
Rear Caliper (Balance)
The rear axle uses the Genuine Brembo OEM Porsche 19Z 4-Piston Caliper with a 380mm carbon-ceramic rotor, giving the X6 rear brake torque that supports stability instead of leaving the rear axle under-braked after a large front upgrade. The E71 factory electronic parking brake system is accounted for during rear-package engineering so the parking-brake function is not ignored in the conversion plan.
Front & rear, engineered together: The 420mm front and 380mm rear carbon-ceramic package is engineered as one brake system so pedal travel, front-to-rear torque balance, ABS behavior, and thermal capacity are considered together. On a high-mass AWD X6, a front-only mismatch can overload the front tires and leave rear contribution behind; this kit sizes both axles around the confirmed trim and wheel package.
Make It Yours — Color & Logo Customization
Every StopFlex kit-upgrade order can be finished with custom caliper colors, a custom caliper logo, and custom rotor hat colors, so the brake package matches your exact build instead of a fixed off-the-shelf look.
- Custom caliper color
- Custom caliper logo
- Custom rotor hat color
Why StopFlex CCB
Lower Unsprung Mass
StopFlex carbon-ceramic rotors are engineered to reduce rotor mass versus comparable iron discs, helping the suspension react cleaner and the steering feel more precise.
High-Temperature Stability
The carbon-silicon-carbide matrix is built for stable braking behavior at temperatures that can push iron rotors into heavy fade.
Rust-Free Rotor Surface
Carbon ceramic does not form orange flash rust after rain, washing, or storage, keeping the visible rotor face cleaner behind open wheels.
Long Street-Service Potential
In normal road use with matched pads and proper bedding, StopFlex CCB rotors are designed for far longer service life than typical iron replacement rotors.
Low Visible Dust
When paired with matched StopFlex pads, the system produces very low visible brake dust compared with conventional iron rotor and pad combinations.
Premium Ceramic-Glaze Appearance
StopFlex's proprietary coating creates a bright, high-end ceramic-glaze finish with subtle glaze texture and a more premium visual character behind open wheels.
Street-Usable Cold Bite
Street Spec and Track-Day Spec rotors are designed for normal first-stop road use, including cold-weather operation. Motorsport Spec is the competition-focused exception.
Continuous Fiber Reinforcement
Long-fiber carbon ceramic construction improves structural strength and thermal durability versus chopped-fiber approaches.
Heat Management Note
Carbon ceramic rotors tolerate extreme surface temperature, but they do not remove every heat-management requirement. During repeated hard stops, heat can still soak into pads, fluid, seals, calipers, wheels, and nearby components. For long track sessions, mountain descents, or sustained aggressive driving, brake cooling and high-temperature fluid are still recommended.
Street / Track-Day / Motorsport Rotor Options
Street Spec
Ceramic coating, cross-drilled face, and large cooling channels.
Best for daily driving and premium street builds that need clean cold bite, low dust, corrosion-free appearance, and long service life.
Track-Day Spec
Ceramic coating, blank face, and honeycomb cooling channels.
Best for fast-road and track-day use where repeated braking stability matters more than maximum visual drilling style.
Motorsport Spec
Uncoated blank face with honeycomb cooling channels.
Best for race-focused builds that run competition pads, high-temperature fluid, cooling strategy, and a proper warm-up window. Not the default street choice.
Package Scope
| Item | Details |
|---|---|
| Front calipers | Genuine Akebono OEM Porsche 10-Piston (10N) Caliper |
| Front CCB rotors | 420mm |
| Rear calipers | Genuine Brembo OEM Porsche 19Z 4-Piston Caliper |
| Rear CCB rotors | 380mm |
| CCB brake pads | Matched for the supplied StopFlex carbon ceramic rotors |
| Rotor hats and floating hardware | Vehicle-specific hardware package |
| Brake lines | Included for complete kit-upgrade orders |
| Color customization | Custom caliper colors, a custom caliper logo, and custom rotor hat colors are available for every kit-upgrade order. |
| Order scope | Default listing is full-car set when front and rear are specified. Front-only or rear-only orders can be arranged after confirmation. |
EPB & Rear Caliper Options
This vehicle leaves the factory with an electronic parking brake (EPB) built into the rear brake, so the rear of the kit is built to keep that EPB working. There are two rear paths. The first is a dual-caliper rear: a main performance caliper handles braking while a dedicated EPB actuator caliper is retained alongside it, so the electronic parking brake, auto-hold, and hill-start assist all keep working; on this path the rear performance caliper can be the TTSPORT EP4 / EP4S 4-piston caliper. The second is an EPB-integrated caliper, a single rear caliper with the electromechanical parking-brake motor built in for a cleaner install with fewer parts behind the wheel; on this path the rear is the TTSPORT EP4 / EP4S 4-piston caliper with integrated EPB. Which path fits best depends on your exact trim and EPB configuration, your budget, your appearance preference, and your wheel size and spoke clearance. Confirm your car's rear-brake configuration with StopFlex before ordering so the correct EPB-compatible rear option is built for your kit.
| Rear option | What it is | Rear caliper | Best when |
|---|---|---|---|
| Dual caliper (EPB retained) | Performance caliper plus a dedicated EPB actuator caliper, both fitted on the rear, so the factory electronic parking brake keeps working. | TTSPORT EP4 / EP4S 4-Piston Caliper | You want guaranteed factory EPB, auto-hold, and hill-start behavior preserved. |
| EPB-integrated caliper | A single rear caliper with the electromechanical parking-brake motor built in, for a cleaner install with fewer parts behind the wheel. | TTSPORT EP4 / EP4S 4-Piston Caliper with integrated EPB | You want a cleaner single-caliper rear with full EPB function. |
FAQ
Will this 420mm kit fit my exact 2008-2014 BMW X6 E71 trim?
StopFlex does not treat every E71 as the same brake fitment. Your exact trim, wheel package, hub geometry, knuckle/upright configuration, and brake option are confirmed before build, then the brackets, rotor-hat offsets, caliper mounting, lines, and hardware are produced for that specific X6.
What wheel size do I need for the 420mm front rotor and 10-piston caliper?
The 420mm front carbon-ceramic rotor requires 21-inch or larger wheels. Diameter alone is not enough; the Genuine Akebono OEM Porsche 10-Piston (10N) Caliper also needs spoke clearance, so StopFlex verifies the wheel model, width, offset, and inner barrel profile before releasing the kit.
Will the electronic parking brake still be addressed with the rear upgrade?
Yes. The E71 X6 has a factory electromechanical parking brake system, so the rear conversion is planned with EPB compatibility in mind rather than treating the rear caliper as a simple hydraulic-only swap. Final configuration is confirmed against the customer’s exact trim before production.
Why choose carbon-ceramic rotors on an E71 X6 instead of another iron big brake kit?
Carbon-ceramic rotors reduce brake dust, resist heat-related fade, and cut rotating mass compared with same-size iron hardware. On the E71 X6, the 420mm front and 380mm rear sizing gives the chassis more thermal capacity while keeping the wheel area cleaner and reducing the weight penalty of a very large brake package.
Need Fitment Confirmation?
Send the exact vehicle details, current rotor sizes, and caliper type before ordering.
