2014-2021 Mercedes-AMG S65 / S63 (W222/V222/C217/A217) Carbon Ceramic Brake Kit
Official Warranty: 1‑year free replacement for quality defects or coating issues under normal (non-track) use.
2014-2021 Mercedes-AMG S65 / S63 (W222/V222/C217/A217) Carbon Ceramic Brake Kit — OEM-Size Replacement
The W222/V222 S-Class sedan and C217/A217 S-Class Coupe/Cabriolet AMG S63 and S65 put high thermal load into the front axle, especially with the 390mm iron front rotor or 420mm factory carbon-ceramic front rotor package. This StopFlex OEM-size replacement kit keeps the factory caliper architecture and matches the listed 390/360mm or 420/360mm rotor layout with carbon-ceramic rotors, pads, hats, and floating hardware. The result is lower brake dust, better heat stability, and reduced rotating mass without converting the car away from its original AMG brake geometry.
- Built for 2014-2021 Mercedes-AMG S63 and S65 W222/V222/C217/A217 applications using the listed 390mm front and 360mm rear iron-brake reference sizes or 420mm front and 360mm rear carbon-ceramic reference sizes.
- OEM-size rotor geometry is intended for cars with the matching factory AMG calipers, so the upgrade focuses on rotor material, heat behavior, dust reduction, and service cost rather than changing caliper position.
- Kit includes carbon-ceramic rotors, matched pads, aluminum hats, and floating hardware for the heavy S63/S65 platform, where repeated high-speed stops load the front brakes before the rear axle reaches the same temperature range.
Fitment Hard Lines
| Field | Specification |
|---|---|
| Vehicle | Mercedes-AMG S65 / S63 (W222/V222/C217/A217) |
| Model years | 2014-2021 |
| Front rotor reference | S65/S63: 390mm, 420mm (CCB) |
| Rear rotor reference | S65/S63: 360mm |
| Page type | OEM-size carbon ceramic replacement |
| Minimum wheel size | 20" (for the 390 mm rotor) |
For OEM replacement orders, StopFlex builds around the factory rotor specification shown for this vehicle. Front floating-caliper setups require manual review before production. If the car uses aftermarket calipers such as Brembo, AP Racing, Alcon, or Wilwood, the order can still be built, but the exact caliper model, pad shape, and rotor dimensions must be confirmed before production.
This setup uses a 390 mm rotor, so the minimum wheel size is 20". Wheels under 20" will not clear the caliper and rotor, and spoke profile and offset affect clearance too — confirm your exact wheels before ordering.
Why StopFlex CCB
Lower Unsprung Mass
StopFlex carbon-ceramic rotors are engineered to reduce rotor mass versus comparable iron discs, helping the suspension react cleaner and the steering feel more precise.
High-Temperature Stability
The carbon-silicon-carbide matrix is built for stable braking behavior at temperatures that can push iron rotors into heavy fade.
Rust-Free Rotor Surface
Carbon ceramic does not form orange flash rust after rain, washing, or storage, keeping the visible rotor face cleaner behind open wheels.
Long Street-Service Potential
In normal road use with matched pads and proper bedding, StopFlex CCB rotors are designed for far longer service life than typical iron replacement rotors.
Low Visible Dust
When paired with matched StopFlex pads, the system produces very low visible brake dust compared with conventional iron rotor and pad combinations.
Premium Ceramic-Glaze Appearance
StopFlex's proprietary coating creates a bright, high-end ceramic-glaze finish with subtle glaze texture and a more premium visual character behind open wheels.
Street-Usable Cold Bite
Street Spec and Track-Day Spec rotors are designed for normal first-stop road use, including cold-weather operation. Motorsport Spec is the competition-focused exception.
Continuous Fiber Reinforcement
Long-fiber carbon ceramic construction improves structural strength and thermal durability versus chopped-fiber approaches.
Custom Rotor Hat Color
Every StopFlex OEM replacement order can be built with a custom rotor hat color, giving the carbon ceramic rotor package a cleaner match with the wheel, body color, and overall build style.
Heat Management Note
Carbon ceramic rotors tolerate extreme surface temperature, but they do not remove every heat-management requirement. During repeated hard stops, heat can still soak into pads, fluid, seals, calipers, wheels, and nearby components. For long track sessions, mountain descents, or sustained aggressive driving, brake cooling and high-temperature fluid are still recommended.
Street / Track-Day / Motorsport Rotor Options
Street Spec
Ceramic coating, cross-drilled face, and large cooling channels.
Best for daily driving and premium street builds that need clean cold bite, low dust, corrosion-free appearance, and long service life.
Track-Day Spec
Ceramic coating, blank face, and honeycomb cooling channels.
Best for fast-road and track-day use where repeated braking stability matters more than maximum visual drilling style.
Motorsport Spec
Uncoated blank face with honeycomb cooling channels.
Best for race-focused builds that run competition pads, high-temperature fluid, cooling strategy, and a proper warm-up window. Not the default street choice.
Package Scope
| Item | Details |
|---|---|
| CCB rotors | Full-car set by default |
| CCB brake pads | Matched for StopFlex carbon ceramic rotors |
| 7075 aluminum floating rotor hats | Vehicle-specific fitment |
| Stainless floating hardware | Full-car hardware set |
| Rotor hat color | Custom rotor hat colors are available for every OEM replacement order. |
| Order scope | Default listing is full-car set. Front-only or rear-only orders can be arranged after confirmation. |
FAQ
Will this fit my 2014-2021 S63 or S65 AMG without changing calipers?
This page is only for W222/V222/C217/A217 S63 and S65 cars that match the listed OEM-size brake references: 390mm front with 360mm rear, or 420mm front carbon-ceramic with 360mm rear. Confirm your VIN, body style, front rotor diameter, rear rotor diameter, and wheel clearance before ordering.
Does the rear electronic parking brake still work?
Yes, the kit is designed around the factory rear brake layout for this S63/S65 platform, including the OEM-style rear service arrangement. The electronic parking brake, auto-hold behavior, and vehicle brake controls remain tied to the factory caliper and control system when the correct 360mm rear fitment is supplied.
Why replace the factory iron or cracked OEM carbon-ceramic rotors with StopFlex carbon ceramic?
The 390mm iron setup can generate heavy dust and heat-related wear on a fast, heavy AMG sedan, coupe, or cabriolet. The 420mm OEM carbon-ceramic setup has strong heat capacity but can be costly to replace at dealer pricing; StopFlex supplies a complete carbon-ceramic rotor, pad, hat, and hardware package for the listed factory sizes.
Is this kit suitable for street use and occasional hard driving?
Yes. The pad and rotor package is intended for road-driven S63/S65 cars that need stable braking, low dust, and reduced rotating mass in the factory AMG brake envelope. For frequent track use, confirm pad compound, bedding procedure, tire choice, and brake-fluid temperature requirements before ordering.
Need Fitment Confirmation?
Send the exact vehicle details, current rotor sizes, and caliper type before ordering.
