2007-2010 Mercedes-AMG CLK63 (C209/A209) Carbon Ceramic Brake Kit
Official Warranty: 1‑year free replacement for quality defects or coating issues under normal (non-track) use.
2007-2010 Mercedes-AMG CLK63 (C209/A209) Carbon Ceramic Brake Kit — OEM-Size Replacement
The 2007-2010 Mercedes-AMG CLK63 uses large OEM AMG iron brakes, but repeated high-speed stops can still drive heat into the 360 mm front and 330 mm rear rotor package. This StopFlex OEM-size carbon-ceramic kit keeps the factory brake envelope while replacing the rotors, pads, hats, and floating hardware with a lower-dust, lower-rotating-mass setup for C209 coupe and A209 cabriolet fitments that match these rotor sizes. The goal is not a big-brake conversion; it is a direct-size replacement for CLK63 owners who want better heat stability and cleaner open-wheel appearance without changing the factory caliper location.
- Built around the CLK63 AMG OEM-size 360 mm front and 330 mm rear rotor references for this C209/A209 application.
- Designed for the non-Black Series CLK63 brake package listed on this page, not the larger 390 mm front Black Series setup.
- Carbon-ceramic rotor mass and low-dust pad behavior address two common M156 CLK63 complaints: front-end brake weight and heavy dark dust on AMG wheels.
Fitment Hard Lines
| Field | Specification |
|---|---|
| Vehicle | Mercedes-AMG CLK63 (C209/A209) |
| Model years | 2007-2010 |
| Front rotor reference | CLK63: 360mm |
| Rear rotor reference | CLK63: 330mm |
| Page type | OEM-size carbon ceramic replacement |
| Minimum wheel size | 19" (for the 360 mm rotor) |
For OEM replacement orders, StopFlex builds around the factory rotor specification shown for this vehicle. Front floating-caliper setups require manual review before production. If the car uses aftermarket calipers such as Brembo, AP Racing, Alcon, or Wilwood, the order can still be built, but the exact caliper model, pad shape, and rotor dimensions must be confirmed before production.
This setup uses a 360 mm rotor, so the minimum wheel size is 19". Wheels under 19" will not clear the caliper and rotor, and spoke profile and offset affect clearance too — confirm your exact wheels before ordering.
Why StopFlex CCB
Lower Unsprung Mass
StopFlex carbon-ceramic rotors are engineered to reduce rotor mass versus comparable iron discs, helping the suspension react cleaner and the steering feel more precise.
High-Temperature Stability
The carbon-silicon-carbide matrix is built for stable braking behavior at temperatures that can push iron rotors into heavy fade.
Rust-Free Rotor Surface
Carbon ceramic does not form orange flash rust after rain, washing, or storage, keeping the visible rotor face cleaner behind open wheels.
Long Street-Service Potential
In normal road use with matched pads and proper bedding, StopFlex CCB rotors are designed for far longer service life than typical iron replacement rotors.
Low Visible Dust
When paired with matched StopFlex pads, the system produces very low visible brake dust compared with conventional iron rotor and pad combinations.
Premium Ceramic-Glaze Appearance
StopFlex's proprietary coating creates a bright, high-end ceramic-glaze finish with subtle glaze texture and a more premium visual character behind open wheels.
Street-Usable Cold Bite
Street Spec and Track-Day Spec rotors are designed for normal first-stop road use, including cold-weather operation. Motorsport Spec is the competition-focused exception.
Continuous Fiber Reinforcement
Long-fiber carbon ceramic construction improves structural strength and thermal durability versus chopped-fiber approaches.
Custom Rotor Hat Color
Every StopFlex OEM replacement order can be built with a custom rotor hat color, giving the carbon ceramic rotor package a cleaner match with the wheel, body color, and overall build style.
Heat Management Note
Carbon ceramic rotors tolerate extreme surface temperature, but they do not remove every heat-management requirement. During repeated hard stops, heat can still soak into pads, fluid, seals, calipers, wheels, and nearby components. For long track sessions, mountain descents, or sustained aggressive driving, brake cooling and high-temperature fluid are still recommended.
Street / Track-Day / Motorsport Rotor Options
Street Spec
Ceramic coating, cross-drilled face, and large cooling channels.
Best for daily driving and premium street builds that need clean cold bite, low dust, corrosion-free appearance, and long service life.
Track-Day Spec
Ceramic coating, blank face, and honeycomb cooling channels.
Best for fast-road and track-day use where repeated braking stability matters more than maximum visual drilling style.
Motorsport Spec
Uncoated blank face with honeycomb cooling channels.
Best for race-focused builds that run competition pads, high-temperature fluid, cooling strategy, and a proper warm-up window. Not the default street choice.
Package Scope
| Item | Details |
|---|---|
| CCB rotors | Full-car set by default |
| CCB brake pads | Matched for StopFlex carbon ceramic rotors |
| 7075 aluminum floating rotor hats | Vehicle-specific fitment |
| Stainless floating hardware | Full-car hardware set |
| Rotor hat color | Custom rotor hat colors are available for every OEM replacement order. |
| Order scope | Default listing is full-car set. Front-only or rear-only orders can be arranged after confirmation. |
FAQ
Will this kit fit every 2007-2010 CLK63 AMG?
No. This page is limited to C209/A209 CLK63 AMG cars that use the listed 360 mm front and 330 mm rear OEM rotor sizes. Confirm your body style, trim, and existing rotor dimensions before ordering, especially if the car has Black Series parts or a prior brake conversion.
Does this replace my factory calipers?
No. This is an OEM-size replacement package with carbon-ceramic rotors, matched pads, hats, and floating hardware. It is intended to work within the factory CLK63 AMG brake layout for the rotor sizes listed on this page.
Will the parking brake still work?
The CLK63 rear brake uses a mechanical parking-brake function at the rear hub, so the rear hat design must match the 330 mm CLK63 application. Confirm your rear rotor size and hub/parking-brake configuration before the kit is built.
Why switch from the factory iron rotors on a CLK63?
Carbon-ceramic rotors reduce rotating and unsprung mass, produce far less visible brake dust, and tolerate repeated heat cycles better than iron in hard mountain or track use. On this car, the payoff is strongest at the 360 mm front axle, where braking heat and weight are concentrated.
Need Fitment Confirmation?
Send the exact vehicle details, current rotor sizes, and caliper type before ordering.
