2008-2016 Audi A5 / S5 / RS5 (B8) CCB Big Brake Kit | Akebono 10N 10-Piston
Official Warranty: 1‑year free replacement for quality defects or coating issues under normal (non-track) use.
We Ship Worldwide
2008-2016 Audi A5 / S5 / RS5 (B8) CCB Big Brake Kit — Genuine Akebono OEM Audi RS 10-Piston (10N) Caliper Front + TTSPORT EP4 4-Piston Caliper with EPB Rear Setup
This StopFlex kit is for B8 Audi A5, S5, and RS5 owners who have outgrown the heat capacity, dust output, or replacement cost of conventional iron brakes. The front axle uses a Genuine Akebono OEM Audi RS 10-Piston (10N) Caliper over a 420mm carbon-ceramic rotor, while the rear uses a TTSPORT EP4 4-Piston Caliper with EPB over a 380mm carbon-ceramic rotor to add rear thermal capacity without giving up the factory electronic parking brake. Because the 420mm front rotor requires a minimum 21-inch wheel and real spoke clearance, every kit is built around the customer's exact trim and wheel package rather than assumed from the B8 chassis name.
- 420mm front carbon-ceramic rotors require 21-inch or larger wheels on the B8 A5/S5/RS5, and spoke clearance must be verified before production.
- Front braking is handled by the exact Genuine Akebono OEM Audi RS 10-Piston (10N) Caliper, paired with StopFlex carbon-ceramic rotors, pads, hats, hardware, and lines.
- Rear braking uses a 380mm carbon-ceramic rotor with a TTSPORT EP4 4-Piston Caliper with EPB, preserving the B8/B8.5 electronic parking-brake function.
Fitment Hard Lines
| Field | Specification |
|---|---|
| Vehicle | Audi A5 / S5 / RS5 (B8) |
| Model years | 2008-2016 |
| Front setup | Genuine Akebono OEM Audi RS 10-Piston (10N) Caliper / 420mm |
| Rear setup | TTSPORT EP4 4-Piston Caliper with EPB / 380mm |
| Page type | Complete CCB kit upgrade |
| Minimum wheel size | 21" (for the 420 mm front rotor) |
Every StopFlex kit is bespoke-engineered for your exact model and trim — the brackets, rotor-hat offsets, and caliper mounting are matched to your specific car, not assumed from the platform. This matters because trims that share a chassis name can differ mechanically: a pure M or performance variant often carries different front knuckles/uprights, hub geometry, and wheel axial (ET) clearance than the standard models in the same family, so a bracket and hat offset that bolt onto one are not the same parts that fit the other. StopFlex supplies the calipers, pads, rotor hats, floating hardware, and brake lines as a matched system built to your confirmed trim. Cars with modified knuckles, modified uprights, or non-factory suspension mounting points must be reviewed before ordering and are not treated as direct-fit.
This setup uses a 420 mm front rotor, so the minimum wheel size is 21". Wheels under 21" will not clear the caliper and rotor, and spoke profile and offset affect clearance too — confirm your exact wheels before ordering.
| Wheel Size (Standard) | Disc Range |
|---|---|
| 15" | 260 mm – 285 mm |
| 16" | 285 mm – 300 mm |
| 17" | 300 mm – 330 mm |
| 18" | 330 mm – 355 mm |
| 19" | 355 mm – 380 mm |
| 20" | 380 mm – 400 mm |
| 21" | 400 mm – 420 mm |
| 22" | 420 mm – 440 mm |
Caliper Overview — Front & Rear Balance
Front Caliper (Primary Upgrade)
The front upgrade uses the Genuine Akebono OEM Audi RS 10-Piston (10N) Caliper, a 10-piston OEM-derived Audi RS caliper selected for high clamp distribution across a large pad shape and a firm, repeatable pedal on a 420mm rotor. Its genuine Akebono provenance matters on this chassis because the caliper architecture was developed for high-performance Audi applications, not adapted from a generic aftermarket casting. StopFlex matches the caliper mounting, bracket geometry, rotor hat offset, and line routing to the confirmed A5, S5, or RS5 trim before the kit is built.
Rear Caliper (Balance)
The rear uses the TTSPORT EP4 4-Piston Caliper with EPB on a 380mm carbon-ceramic rotor to add rear-axle heat capacity and braking stability instead of leaving the rear as a cosmetic afterthought. The EP4 uses four hydraulic service pistons plus a dedicated EPB actuator piston, so the B8/B8.5 Audi electronic parking brake remains functional.
Front & rear, engineered together: A 420mm front-only conversion can overload the front axle and leave rear thermal capacity unchanged, so this StopFlex kit engineers the 420mm front and 380mm rear package as one brake system. The TTSPORT EP4 rear caliper shares the EP4S engineering concept, including a two-piece forged-aluminum body, heat-insulated pistons with dust boots, and EPB integration, giving the car real rear braking hardware to match the Audi RS 10-piston front setup.
Make It Yours — Color & Logo Customization
Every StopFlex kit-upgrade order can be finished with custom caliper colors, a custom caliper logo, and custom rotor hat colors, so the brake package matches your exact build instead of a fixed off-the-shelf look.
- Custom caliper color
- Custom caliper logo
- Custom rotor hat color
Why StopFlex CCB
Lower Unsprung Mass
StopFlex carbon-ceramic rotors are engineered to reduce rotor mass versus comparable iron discs, helping the suspension react cleaner and the steering feel more precise.
High-Temperature Stability
The carbon-silicon-carbide matrix is built for stable braking behavior at temperatures that can push iron rotors into heavy fade.
Rust-Free Rotor Surface
Carbon ceramic does not form orange flash rust after rain, washing, or storage, keeping the visible rotor face cleaner behind open wheels.
Long Street-Service Potential
In normal road use with matched pads and proper bedding, StopFlex CCB rotors are designed for far longer service life than typical iron replacement rotors.
Low Visible Dust
When paired with matched StopFlex pads, the system produces very low visible brake dust compared with conventional iron rotor and pad combinations.
Premium Ceramic-Glaze Appearance
StopFlex's proprietary coating creates a bright, high-end ceramic-glaze finish with subtle glaze texture and a more premium visual character behind open wheels.
Street-Usable Cold Bite
Street Spec and Track-Day Spec rotors are designed for normal first-stop road use, including cold-weather operation. Motorsport Spec is the competition-focused exception.
Continuous Fiber Reinforcement
Long-fiber carbon ceramic construction improves structural strength and thermal durability versus chopped-fiber approaches.
Heat Management Note
Carbon ceramic rotors tolerate extreme surface temperature, but they do not remove every heat-management requirement. During repeated hard stops, heat can still soak into pads, fluid, seals, calipers, wheels, and nearby components. For long track sessions, mountain descents, or sustained aggressive driving, brake cooling and high-temperature fluid are still recommended.
Street / Track-Day / Motorsport Rotor Options
Street Spec
Ceramic coating, cross-drilled face, and large cooling channels.
Best for daily driving and premium street builds that need clean cold bite, low dust, corrosion-free appearance, and long service life.
Track-Day Spec
Ceramic coating, blank face, and honeycomb cooling channels.
Best for fast-road and track-day use where repeated braking stability matters more than maximum visual drilling style.
Motorsport Spec
Uncoated blank face with honeycomb cooling channels.
Best for race-focused builds that run competition pads, high-temperature fluid, cooling strategy, and a proper warm-up window. Not the default street choice.
Package Scope
| Item | Details |
|---|---|
| Front calipers | Genuine Akebono OEM Audi RS 10-Piston (10N) Caliper |
| Front CCB rotors | 420mm |
| Rear calipers | TTSPORT EP4 4-Piston Caliper with EPB |
| Rear CCB rotors | 380mm |
| CCB brake pads | Matched for the supplied StopFlex carbon ceramic rotors |
| Rotor hats and floating hardware | Vehicle-specific hardware package |
| Brake lines | Included for complete kit-upgrade orders |
| Color customization | Custom caliper colors, a custom caliper logo, and custom rotor hat colors are available for every kit-upgrade order. |
| Order scope | Default listing is full-car set when front and rear are specified. Front-only or rear-only orders can be arranged after confirmation. |
EPB & Rear Caliper Options
This vehicle leaves the factory with an electronic parking brake (EPB) built into the rear brake, so the rear of the kit is built to keep that EPB working. There are two rear paths. The first is a dual-caliper rear: a main performance caliper handles braking while a dedicated EPB actuator caliper is retained alongside it, so the electronic parking brake, auto-hold, and hill-start assist all keep working; on this path the rear performance caliper can be the TTSPORT EP4 / EP4S 4-piston caliper. The second is an EPB-integrated caliper, a single rear caliper with the electromechanical parking-brake motor built in for a cleaner install with fewer parts behind the wheel; on this path the rear is the TTSPORT EP4 / EP4S 4-piston caliper with integrated EPB. Which path fits best depends on your exact trim and EPB configuration, your budget, your appearance preference, and your wheel size and spoke clearance. Confirm your car's rear-brake configuration with StopFlex before ordering so the correct EPB-compatible rear option is built for your kit.
| Rear option | What it is | Rear caliper | Best when |
|---|---|---|---|
| Dual caliper (EPB retained) | Performance caliper plus a dedicated EPB actuator caliper, both fitted on the rear, so the factory electronic parking brake keeps working. | TTSPORT EP4 / EP4S 4-Piston Caliper | You want guaranteed factory EPB, auto-hold, and hill-start behavior preserved. |
| EPB-integrated caliper | A single rear caliper with the electromechanical parking-brake motor built in, for a cleaner install with fewer parts behind the wheel. | TTSPORT EP4 / EP4S 4-Piston Caliper with integrated EPB | You want a cleaner single-caliper rear with full EPB function. |
TTSPORT EP4S rear caliper specification (the EP4 shares the same engineering, slightly more compact):
| Specification | EP4S |
|---|---|
| Axle position | Rear |
| Piston count | 4 hydraulic + 1 EPB actuator |
| Piston type | Two-piece heat-insulated, dust boots + EPB actuator |
| Piston diameter | 28 mm × 4 / 27 mm × 1 |
| Total piston area | 30.4 cm² per caliper |
| Manufacturing process | Two-piece forged aluminum body |
| Net weight | 4.50 kg per caliper (no pads) |
| Surface finish | High-temperature gloss coating |
| Recommended wheel size | 18 in or larger |
FAQ
Will this kit fit my exact 2008-2016 A5, S5, or RS5?
Fitment is not treated as a platform-wide B8 bolt-on. StopFlex confirms the exact model year, trim, drivetrain, hub/upright configuration, and wheel data, then builds the brackets, rotor-hat offsets, and caliper mounting for that specific car.
What wheels are required for the 420mm front rotor?
The 420mm front carbon-ceramic rotor requires 21-inch or larger wheels. Wheel diameter alone is not enough; StopFlex also checks spoke clearance against the Genuine Akebono OEM Audi RS 10-Piston (10N) Caliper before approving the build.
Will the electronic parking brake still work?
Yes. The rear package uses the TTSPORT EP4 4-Piston Caliper with EPB, which has four hydraulic service pistons for braking and a dedicated EPB actuator piston to retain the Audi electronic parking-brake function.
Why choose this carbon-ceramic kit instead of another iron big-brake setup?
Carbon-ceramic rotors reduce brake dust and unsprung mass compared with iron rotors while adding heat capacity for repeated high-speed stops. On the B8 A5/S5/RS5, the 420mm front and 380mm rear layout is aimed at owners who want track-capable thermal control, cleaner open wheels, and a complete front/rear brake system rather than a front-only caliper swap.
Need Fitment Confirmation?
Send the exact vehicle details, current rotor sizes, and caliper type before ordering.
